Capture Crisp Live Image with Digital Camera SC180
Detail. Speed. Comfort.
18-megapixel SC180 color camera reveals your sample’s fine details and structures. The excellent spatial resolution provided by the camera’s sensor element combined with an 18 million pixel count exploits the full optical resolution of the objectives, enabling you to make observations exclusively on-screen without using the eyepieces and fostering effective collaboration and audience engagement during full-screen presentations.
Capture and document tiny details
With almost four times more pixels than a standard microscope camera, the SC180 camera utilizes the optical resolution of the objectives, making it a good choice for any application that requires display, measurement, and analysis to document your sample´s details and structures.
Color profiling technology provides excellent color fidelity and reproduction without user intervention.
Fully integrated ICC color reproduction technology preserves even the small color details and subtle color variances. At every stage, from eyepieces to the monitor, an accurate image is acquired and displayed.
SC180 specifications
| Image Sensor | Color CMOS |
|---|---|
| Resolution (max.) | 4912 × 3684 pixels (4:3) |
| 3840 × 2160 pixels (4K UHD 16:9) | |
| 1920 × 1080 pixels (Full HD 16:9) | |
| Pixel Size | 1.25 × 1.25 µm |
| Binning | 2 × 2, 4 × 4 |
| A/D Converter (Bit Depth) | 12 bits |
| Exposure Times | 22 µs–1s |
| Live Frame Rates | 10.5 fps at 4,912 × 3,684 pixels (4:3) |
| 23.6 fps at 2,456 × 1,842 pixels (4:3) | |
| 45 fps at 1,224 × 920 pixels (4:3) | |
| 14fps at 4,912 × 2,762 pixels (16:9) | |
| 25 fps at 3,840 × 2,160 pixels (4K UHD 16:9) | |
| 31 fps at 1,920 × 1,080 pixels (Full HD 16:9) | |
| 59 fps at 1,224 × 688 pixels (16:9) | |
| Cooling System | Passively cooled |
| External Trigger | - |
| Data Transfer | USB 3.0 |
| Color Profiles | Olympus real-time ICC color profiles |
| Partial Readout | ✓ |
| Remarks | USB 3.0 interface |
| 4K UHD and Full HD support, 16:9 aspect ratio | |
| Automatic White Balance (AWB) | |
| Focus Peaking Manual Focus Assist | |
| OSIA - Olympus Smart Image Averaging (active noise reduction) | |
| Fast Live (high frame rate in low light conditions) | |
| PC Control | Microsoft Windows 10 (64 bit only) |
| Microsoft Windows 8/8.1 (64 bit only) | |
| Microsoft Windows 7 (64 bit only) | |
| Dimensions (W × D × H) | 58 mm × 58 mm × 32 mm |
| Weight | Approx. 188 g |
| Camera Mount | C-mount |
Specification are subject to change without notice or obligation on the part of the manufacturer
