Capture Crisp Live Image with Digital Camera LC35
Combining quality brightfield images with affordability, the LC35 digital microscope camera is an excellent value for materials science imaging.
Navigate around your sample quickly and easily with an up to 40 fps frame rate to achieve precise focusing and fast image capture
Works well for many types of samples and observation conditions thanks to versatile exposure times and resolution modes
LC35 specifications
| mage Sensor | 1/2.5-inch color CMOS |
|---|---|
| Resolution (max.) | 2,160 × 1,620 pixels |
| 1920 × 1080 pixels (full HD 16:9) | |
| 1,296 × 972 pixels (fast mode) | |
| Pixel Size | 2.64 × 2.64 µm |
| Subsampling | 2 × 2 |
| A/D Converter (Bit Depth) | 10-bits |
| Exposure Time | 25 µs–1.5 sec |
| Live Frame Rates* | Up to 19 fps at 2,160 × 1,620 pixels (@ full resolution) |
| Up to 25 fps at 1920 × 1080 pixels (@ full HD) | |
| Up to 40 fps at 1,296 × 972 pixels (@ fast mode) | |
| Data Transfer | USB 3.1 Gen1 Type-C |
| PC Requirements | CPU: Intel® Xeon, Intel® Core i5, i7, i9, or the equivalent RAM: 8 GB Recommended: 4 or more physical CPU cores 8 GB RAM (dual channel) |
| PC Control | Windows 10 (64-bit) |
| Imaging Platform | LCmicro Olympus Stream Start, Basic, and Essentials v.2.5 or higher** / PRECiV Capture, Core, and Pro v1.1 or higher*** DP2-TWAIN |
*Frame rate may decrease depending on the condition of your PC, monitor resolution, and/or software.
** Service update for v. 2.5 required
***Service update for v.1.1 required
Specification are subject to change without notice or obligation on the part of the manufacturer
Digital Cameras for Microscope
DP75 is tailored for a range of applications and enables you capture high-resolution brightfield, darkfield, MIX (brightfield and darkfield), polarization, DIC, fluorescence, and near-infrared (NIR) observation* images.
* A microscope system for near-infrared observation is required.
The DP28 digital microscope camera combines powerful features, precise color accuracy, and up to 4K resolution across a wide field of view to provide high-resolution images of your inspection samples that are free from artifacts. Make your inspections fast and efficient with images that are sharp and clear, even when moving the stage.
DP23 digital microscope camera combines high image quality with precise color accuracy and convenient features to make your workflow easier. Providing advanced functions balanced with outstanding value, the DP23 camera is instrumental to perform almost any industrial imaging application.
DP23M 6.4-megapixel digital microscope camera has a spectral response from visible light up to 1000 nm, making it ideal for near-infrared (IR) imaging. The camera is also equipped to provide dependable, high-quality gray scale and infrared microscopy images.
LC35 digital microscope camera provides cost-effective brightfield images for a range of samples under different observation conditions. With a 3.5-megapixel CMOS sensor, and up to 40 fps frame rate, and easy integration with Olympus microscopes and software, the LC35 color microscope camera balances image quality with affordability.
The high-resolution, 18-megapixel SC180 color camera reveals your sample’s fine details and structures. The camera enables insightful observations by resolving more digitally-captured information on-screen than what you could otherwise see through the eyepieces.
Convert each microscope into a wireless imaging system and enhance collaboration in the classroom.
